AEVTS300-EA
ActiveAltran Magnetics, LLC
DC CONTACTOR 300A 48 VDC COIL
Deep-Dive with AI
Search across all available documentation for this part.
AEVTS300-EA
ActiveAltran Magnetics, LLC
DC CONTACTOR 300A 48 VDC COIL
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AEVTS300-EA |
|---|---|
| Coil Voltage | 48 VDC |
| Contact Form | SPST-NO (DM) (1 Form X) |
| Contact Rating (Current) | 300 A |
| Features | Auxiliary Contacts |
| Mounting Type | Chassis Mount |
| Must Operate Voltage | 36 VDC |
| Must Release Voltage | 4 VDC |
| Operate Time | 40 ms |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Release Time | 30 ms |
| Switching Voltage [Max] | 1800 VDC |
| Termination Style | Connector, Stud |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 184.85 | |
Description
General part information
AEVTS300-EA
DC CONTACTOR 300A 48 VDC COIL
Documents
Technical documentation and resources
No documents available
