APS18AFA032G-6BTM1GW
ActiveApacer Memory America
SSD 32GB 1.8" MLC SATAIII 3.3-5V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
APS18AFA032G-6BTM1GW
ActiveApacer Memory America
SSD 32GB 1.8" MLC SATAIII 3.3-5V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | APS18AFA032G-6BTM1GW |
|---|---|
| Current - Max [Max] | 360 mA |
| Form Factor | 1.8 in |
| Memory Size | 32 GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (MLC) |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Size / Dimension [x] | 78.5 mm |
| Size / Dimension [y] | 54 mm |
| Size / Dimension [z] | 5 mm |
| Speed - Read | 360 MB/s |
| Speed - Write | 100 MB/s |
| Type | SATA III |
| Voltage - Supply | 5 V, 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 110.79 | |
Description
General part information
APS18AFA032G-6BTM1GW
Solid State Drive (SSD) FLASH - NAND (MLC) 32GB SATA III 1.8" 3.3V, 5V
