SPH4012H820MT
ActiveShenzhen Sunlord Electronics Co., Ltd.
FIXED IND 82UH 360MA 2.04OHM SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SPH4012H820MT
ActiveShenzhen Sunlord Electronics Co., Ltd.
FIXED IND 82UH 360MA 2.04OHM SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SPH4012H820MT |
|---|---|
| Current Rating (Amps) | 360 mA |
| DC Resistance (DCR) [Max] | 2.04 Ohm |
| Height - Seated (Max) [Max] | 1.2 mm |
| Height - Seated (Max) [Max] | 0.047 in |
| Inductance | 82 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension [x] | 4 mm |
| Size / Dimension [x] | 0.157 " |
| Size / Dimension [y] | 0.157 in |
| Size / Dimension [y] | 4 mm |
| Tolerance | 20 % |
| Type | Wirewound, Drum Core |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 4500 | $ 0.20 | |
Description
General part information
SPH4012H820MT
82 µH Shielded Drum Core, Wirewound Inductor 360 mA 2.04Ohm Max Nonstandard
