D1WEL0805MR013F-T5
ActiveThin Film Technology Corp.
RES 0.013 OHM 1% 3/4W 0805
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
D1WEL0805MR013F-T5
ActiveThin Film Technology Corp.
RES 0.013 OHM 1% 3/4W 0805
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | D1WEL0805MR013F-T5 |
|---|---|
| Features | Flame Retardant Coating, Moisture Resistant, Current Sense, Anti-Sulfur, Safety |
| Height - Seated (Max) [Max] [z] | 0.85 mm |
| Height - Seated (Max) [Max] [z] | 0.033 " |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 0805 |
| Power (Watts) | 0.75 W |
| Power (Watts) | 0.75 W |
| Resistance | 13 mOhms |
| Size / Dimension [x] | 0.083 in |
| Size / Dimension [x] | 2.11 mm |
| Size / Dimension [y] | 0.053 in |
| Size / Dimension [y] | 1.35 mm |
| Supplier Device Package | 0805 |
| Temperature Coefficient | 50 ppm/°C |
| Tolerance | 1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.57 | |
| 10 | $ 0.32 | |||
| 25 | $ 0.26 | |||
| 50 | $ 0.22 | |||
| 100 | $ 0.19 | |||
| 250 | $ 0.16 | |||
| 500 | $ 0.14 | |||
| 1000 | $ 0.12 | |||
| Tape & Reel (TR) | 5000 | $ 0.09 | ||
| 10000 | $ 0.09 | |||
Description
General part information
D1WEL0805MR013F-T5
13 mOhms ±1% 0.75W, 3/4W Chip Resistor 0805 (2012 Metric) Anti-Sulfur, Current Sense, Flame Retardant Coating, Moisture Resistant, Safety Metal Foil
