Technical Specifications
Parameters and characteristics for this part
| Specification | T1691UYG-20C001712U1930 |
|---|---|
| Color | Yellow-Green |
| Current - Test | 20 mA |
| Height (Max) [Max] [z] | 2 mm |
| Lens Size [diameter] | 2 mm |
| Lens Transparency | Clear |
| Millicandela Rating | 71.5 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 2-PLCC |
| Supplier Device Package | 2-PLCC |
| Viewing Angle | 120 ° |
| Voltage - Forward (Vf) (Typ) | 2.1 V |
| Wavelength - Dominant | 571 nm |
| Wavelength - Peak | 573 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.10 | |
| 10 | $ 0.07 | |||
| Digi-Reel® | 1 | $ 0.10 | ||
| 10 | $ 0.07 | |||
| Tape & Reel (TR) | 2000 | $ 0.07 | ||
Description
General part information
T1691UYG-20C001712U1930
Yellow-Green 571nm LED Indication - Discrete 2.1V 2-PLCC
