5435530

Active

Phoenix Contact

CONN TERMINAL BLOCK F 2 POS 5MM SCREW RA CABLE MOUNT 12A CARDBOARD

Search across all available documentation for this part.

Active

Phoenix Contact

CONN TERMINAL BLOCK F 2 POS 5MM SCREW RA CABLE MOUNT 12A CARDBOARD

Technical Specifications

Parameters and characteristics for this part

Specification	5435530

Color	Gray
Contact Mating Finish	Tin
Current - IEC	12 A
Features	Mating Flange
Housing Material	Polyamide (PA), Nylon
Insulation Height	0.591 in
Insulation Height	15 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Number of Positions	2
Pitch [x]	5 mm
Pitch [x]	0.197 in
Positions Per Level	2
Screw Size	M3
Termination Style	Screw
Torque - Screw [Max]	0.5 Nm
Torque - Screw [Max]	4.4 Lb-In
Torque - Screw [Min]	0.4 Nm
Torque - Screw [Min]	3.5 Lb-In
Type	Plug, Female Sockets
Voltage - IEC	630 V
Voltage - UL	300 V
Wire Gauge or Range - AWG [Max]	30 AWG
Wire Gauge or Range - AWG [Min]	12 AWG
Wire Gauge or Range - mm² [Max]	2.5 mm²
Wire Gauge or Range - mm² [Min]	0.2 mm²
Wire Strip Length	7 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 1.01

General part information

2 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) 180° Free Hanging (In-Line)
