LLG2G181MELA25

Active

NICHICON

CAP ALUMINUM LYTIC 180UF 400V 20% (25 X 25MM) SNAP-IN 10MM 1160MA 2000H 85°C BULK

Search across all available documentation for this part.

Active

NICHICON

CAP ALUMINUM LYTIC 180UF 400V 20% (25 X 25MM) SNAP-IN 10MM 1160MA 2000H 85°C BULK

Technical Specifications

Parameters and characteristics for this part

Specification	LLG2G181MELA25

Applications	General Purpose
Capacitance	180 çF
Height - Seated (Max) [Max] [z]	1.063 in
Height - Seated (Max) [Max] [z]	27 mm
Lead Spacing	0.394 in
Lead Spacing	10 mm
Lifetime @ Temp.	2000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Package / Case	Radial, Can - Snap-In
Polarization	Polar
Ripple Current @ High Frequency	1.6588 A
Ripple Current @ Low Frequency	1.16 A
Size / Dimension [diameter]	25 mm
Size / Dimension [diameter]	0.984 "
Tolerance	20 %
Voltage - Rated	400 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

180 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 2000 Hrs @ 85°C
