RAC40-24SA
ObsoleteRECOM Power
AC/DC CONVERTER 24V 40W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
RAC40-24SA
ObsoleteRECOM Power
AC/DC CONVERTER 24V 40W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | RAC40-24SA |
|---|---|
| Applications | Medical |
| Approval Agency | cULus, CE |
| Current - Output (Max) [Max] | 1.67 A |
| Efficiency | 83 % |
| Features | Universal Input |
| Line Regulation | 0.5 % |
| Load Regulation | 1 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 7-DIP Module, 5 Leads |
| Power (Watts) | 40 W |
| Size / Dimension [x] | 89 mm |
| Size / Dimension [x] | 3.5 in |
| Size / Dimension [y] | 63.5 mm |
| Size / Dimension [y] | 2.5 in |
| Size / Dimension [z] | 1.08 " |
| Size / Dimension [z] | 27.5 mm |
| Standard Number | 60601-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Output 1 | 24 V |
| Weight | 280.32 g |
| Weight | 0.618 lb |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
RAC40-24SA
Enclosed AC DC Converters 1 Output 24V 1.67A 90 ~ 264 VAC Input
