121-410-003
ObsoleteI.O. Interconnect
CABLE MOD COIL 4COND SILVER 5'
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
121-410-003
ObsoleteI.O. Interconnect
CABLE MOD COIL 4COND SILVER 5'
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 121-410-003 |
|---|---|
| Cable Height [z] | 0.098 in |
| Cable Height [z] | 2.5 mm |
| Cable Type | Coil |
| Cable Width | 0.189 in |
| Cable Width | 4.8 mm |
| Coil Diameter [diameter] | 0.551 in |
| Coil Diameter [diameter] | 14 mm |
| Conductor Material | Copper, Bare |
| Conductor Strand [custom] | 0.0047 in |
| Conductor Strand [custom] | 12 |
| Jacket (Insulation) Material | Polypropylene (PP) |
| Jacket Color | Silver |
| Length - Coil Extended [x] | 1.52 m |
| Length - Coil Extended [x] | 5 ft |
| Length - Coil Retracted [x] | 1.42 ' |
| Length - Coil Retracted [x] | 0.43 m |
| Number of Conductors | 4 |
| Operating Temperature | 80 °C |
| Shielding | Unshielded |
| Voltage | 30 V |
| Wire Gauge | 26 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.90 | |
| 10 | $ 0.88 | |||
| 25 | $ 0.86 | |||
Description
General part information
121-410-003
4 Conductor Modular Coil Cable Silver 5' (1.52m)
