PK25FG160
ActiveSanRex Corporation
THYRISTOR MODULE 1600V 25A
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PK25FG160
ActiveSanRex Corporation
THYRISTOR MODULE 1600V 25A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PK25FG160 |
|---|---|
| Current - Gate Trigger (Igt) (Max) [Max] | 50 mA |
| Current - On State (It (AV)) (Max) [Max] | 25 A |
| Current - On State (It (RMS)) (Max) | 39 A |
| Mounting Type | Chassis Mount |
| Number of SCRs, Diodes | 2 SCRs |
| Operating Temperature [Max] | 125 ¯C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Module |
| Structure | Series Connection - All SCRs |
| Voltage - Off State | 1.6 kV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 26 | $ 31.53 | |
Description
General part information
PK25FG160
SCR Module 1.6 kV 39 A Series Connection - All SCRs Chassis Mount Module
