Technical Specifications
Parameters and characteristics for this part
| Specification | AT04-12PD-RD01 |
|---|---|
| Color | Brown |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Male Pin |
| Fastening Type | Latch Holder |
| Features | Sealed |
| Insulation Material | Thermoplastic |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 12 |
| Number of Rows | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 5.63 | |
| 10 | $ 5.11 | |||
| 25 | $ 4.84 | |||
| 50 | $ 4.73 | |||
| 220 | $ 4.50 | |||
| 440 | $ 3.83 | |||
| 1100 | $ 3.27 | |||
| 2640 | $ 3.04 | |||
Description
General part information
AT04-12PD-RD01
12 Rectangular Connectors - Housings Receptacle Brown
Documents
Technical documentation and resources
