PS1608MT2R2
ActiveViking Technology
FIXED IND 2.2UH 1.8A 50 MOHM SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PS1608MT2R2
ActiveViking Technology
FIXED IND 2.2UH 1.8A 50 MOHM SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PS1608MT2R2 |
|---|---|
| Current - Saturation (Isat) | 920 mA |
| Current Rating (Amps) | 1.8 A |
| DC Resistance (DCR) | 50 mOhm |
| Frequency - Self Resonant | 120 MHz |
| Inductance | 2.2 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Q @ Freq | 40, 200 kHz |
| Shielding | Shielded |
| Size / Dimension [x] | 6.6 mm |
| Size / Dimension [x] | 0.26 in |
| Size / Dimension [y] | 4.54 mm |
| Size / Dimension [y] | 0.179 " |
| Tolerance | 20 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1 | $ 0.29 | |
Description
General part information
PS1608MT2R2
2.2 µH Shielded Inductor 1.8 A 50mOhm Max Nonstandard
