LLPG402-3C3C3J2C-WHT-120
ActiveMobile Mark Antenna Solutions
4-CABLE 2X4G/LTE WIFI GNSS MOBIL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | LLPG402-3C3C3J2C-WHT-120 |
|---|---|
| Antenna Type | Dome |
| Applications | 4G/LTE, GNSS, Wi-Fi |
| Features | Cable |
| Features | 3 m |
| Frequency (Center/Band) | 827 MHz, 5.5 GHz, 2.45 GHz, 2.7 GHz |
| Frequency Group | Wide Band |
| Frequency Range [Max] | 3.7 GHz, 6 GHz, 2.5 GHz, 960 MHz |
| Frequency Range [Min] | 694 MHz, 2.4 GHz, 1.71 GHz, 4.9 GHz |
| Gain | 26 dBi |
| Height (Max) [Max] | 1.25 in |
| Height (Max) [Max] | 31.75 mm |
| Ingress Protection | IP67 |
| Mounting Type | Surface Mount |
| Number of Bands | 4 |
| Power - Max [Max] | 10 W |
| RF Family/Standard | Cellular, WiFi |
| VSWR | 2 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 201.60 | |
Description
General part information
LLPG402-3C3C3J2C-WHT-120
RF ANTENNA 4G/LTE, Wi-Fi, GNSS Dome SMA Male Surface Mount
