CTCDRH5D28F-270N
ActiveCentral Technologies
27UH SMD SHIELDED POWR INDUCTOR
Deep-Dive with AI
Search across all available documentation for this part.
CTCDRH5D28F-270N
ActiveCentral Technologies
27UH SMD SHIELDED POWR INDUCTOR
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CTCDRH5D28F-270N |
|---|---|
| Current - Saturation (Isat) | 850 mA |
| DC Resistance (DCR) | 175 mOhm |
| Height - Seated (Max) | 3 mm |
| Height - Seated (Max) [Max] | 0.118 in |
| Inductance | 27 µH |
| Inductance Frequency - Test | 10 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -30 ░C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension [x] | 0.224 in |
| Size / Dimension [x] | 5.7 mm |
| Size / Dimension [y] | 5.7 mm |
| Size / Dimension [y] | 0.224 in |
| Tolerance | 30 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1 | $ 1.34 | |
| 500 | $ 1.09 | |||
| 1000 | $ 0.84 | |||
Description
General part information
CTCDRH5D28F-270N
27 µH Shielded Inductor 175mOhm Max Nonstandard
Documents
Technical documentation and resources
No documents available
