Technical Specifications
Parameters and characteristics for this part
| Specification | WLS-PST120W51010J-2728S |
|---|---|
| CCT (K) | 6000 K |
| CCT (K) [Max] | 6500 K |
| CCT (K) [Min] | 5500 K |
| Color | Cool, White |
| Configuration | Rectangle |
| CRI (Color Rendering Index) | 90 |
| Current - Max [Max] | 9 A |
| Height [z] | 4.6 mm |
| Lens Type | Flat |
| Light Emitting Surface (LES) [x] | 4.16 mm |
| Light Emitting Surface (LES) [y] | 4.16 mm |
| Luminous Flux @ Current/Temperature | 5000 lm |
| Luminous Flux @ Current/Temperature [Max] | 5500 lm |
| Luminous Flux @ Current/Temperature [Min] | 4500 lm |
| Size / Dimension [x] | 41.75 mm |
| Size / Dimension [y] | 28 mm |
| Type | LED Module |
| Viewing Angle | 120 ° |
| Voltage - Forward (Vf) (Typ) | 13 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Case | 1 | $ 14.28 | |
| 300 | $ 13.57 | |||
| 500 | $ 12.85 | |||
| 1000 | $ 12.14 | |||
Description
General part information
WLS-PST120W51010J-2728S
LED Lighting COBs Engines Modules LED Module - White, Cool Rectangle
