SVZ1AM471F9RE00RAXXX
ActiveAishi Capacitors (Hunan Aihua Group
CAP ALUM POLY 470UF 20% 10V SMD
Deep-Dive with AI
Search across all available documentation for this part.
SVZ1AM471F9RE00RAXXX
ActiveAishi Capacitors (Hunan Aihua Group
CAP ALUM POLY 470UF 20% 10V SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SVZ1AM471F9RE00RAXXX |
|---|---|
| Applications | General Purpose |
| Capacitance | 470 µF |
| ESR (Equivalent Series Resistance) | 22 mOhms |
| Height - Seated (Max) [Max] | 0.394 in |
| Height - Seated (Max) [Max] | 10 mm |
| Lifetime @ Temp. | 2000 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Radial, Can - SMD |
| Ripple Current @ High Frequency | 3.4 A |
| Size / Dimension [diameter] | 0.315 " |
| Size / Dimension [diameter] | 8 mm |
| Surface Mount Land Size [x] | 0.327 " |
| Surface Mount Land Size [x] | 8.3 mm |
| Surface Mount Land Size [y] | 8.3 mm |
| Surface Mount Land Size [y] | 0.327 in |
| Tolerance | 20 % |
| Type | Polymer |
| Voltage - Rated | 10 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.55 | |
| 10 | $ 0.37 | |||
| 50 | $ 0.29 | |||
| 100 | $ 0.24 | |||
| Digi-Reel® | 1 | $ 0.55 | ||
| 10 | $ 0.37 | |||
| 50 | $ 0.29 | |||
| 100 | $ 0.24 | |||
| Tape & Reel (TR) | 600 | $ 0.19 | ||
| 1200 | $ 0.17 | |||
| 1800 | $ 0.16 | |||
| 3000 | $ 0.16 | |||
| 4200 | $ 0.15 | |||
| 6000 | $ 0.15 | |||
| 15000 | $ 0.13 | |||
| 30000 | $ 0.13 | |||
| 60000 | $ 0.12 | |||
Description
General part information
SVZ1AM471F9RE00RAXXX
470 µF 10 V Aluminum - Polymer Capacitors Radial, Can - SMD 22mOhm 2000 Hrs @ 105°C
Documents
Technical documentation and resources
No documents available
