AMLB-3670Z
Activeaimtec
LED DRIVER CC AC/DC 14-32V 700MA
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AMLB-3670Z
Activeaimtec
LED DRIVER CC AC/DC 14-32V 700MA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AMLB-3670Z |
|---|---|
| Approval Agency | CE |
| Current - Output (Max) [Max] | 700 mA |
| Dimming | Analog, PWM |
| Efficiency | 94 % |
| Features | OVP, UVLO, SCP, OCP, OTP |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 6-DIP Module |
| Power (Watts) | 33.6 W |
| Size / Dimension [x] | 2.03 in |
| Size / Dimension [x] | 51.5 mm |
| Size / Dimension [y] | 1.03 in |
| Size / Dimension [y] | 26.1 mm |
| Size / Dimension [z] | 0.62 in |
| Size / Dimension [z] | 15.8 mm |
| Standard Number | 60950-1, UL 8750 |
| Topology | AC DC Converter |
| Type | Constant Current |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 9 V |
| Voltage - Output [Max] | 32 VDC |
| Voltage - Output [Min] | 14 V |
| Weight | 0.084 lb |
| Weight | 38 g |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 62.90 | |
| 5 | $ 56.36 | |||
| 10 | $ 54.95 | |||
| 15 | $ 54.40 | |||
| 25 | $ 53.31 | |||
| 50 | $ 52.24 | |||
| 75 | $ 49.89 | |||
| 100 | $ 44.10 | |||
| 200 | $ 42.77 | |||
Description
General part information
AMLB-3670Z
700mA 14 ~ 32V Constant Current LED Driver AC DC Converter Topology 1 Output
