304212
ActiveAmerican Electrical Inc.
AVK 4RD TERMINAL BLOCK GREEN 600
Deep-Dive with AI
Search across all available documentation for this part.
304212
ActiveAmerican Electrical Inc.
AVK 4RD TERMINAL BLOCK GREEN 600
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 304212 |
|---|---|
| Color | Green |
| Current - IEC | 32 A |
| Current - UL | 30 A |
| Material - Insulation | Thermoplastic |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Stripping Length | 10 mm |
| Terminal - Width [y] | 6 mm |
| Termination Style | Screw |
| Type | Feed Through |
| Voltage - IEC | 750 V |
| Voltage - UL | 600 V |
| Wire Gauge or Range - AWG [Max] | 26 AWG |
| Wire Gauge or Range - AWG [Min] | 10 AWG |
| Wire Gauge or Range - mm˛ [Max] | 6 mm˛ |
| Wire Gauge or Range - mm˛ [Min] | 0.5 mm˛ |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 100 | $ 0.73 | |
Description
General part information
304212
Terminal Block Connector 2 Position Feed Through Green 10-26 AWG
Documents
Technical documentation and resources
No documents available
