SP-90W
ActiveUticor Technologies
AC/DC DIN RAIL SUPPLY 24V 90W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SP-90W
ActiveUticor Technologies
AC/DC DIN RAIL SUPPLY 24V 90W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SP-90W |
|---|---|
| AC Voltage - Input [Max] | 264 VAC |
| AC Voltage - Input [Min] | 85 VAC |
| Applications | Industrial |
| Approval Agency | cUL, UL, CE |
| Current - Output (Max) [Max] | 3.75 A |
| Efficiency | 88 % |
| Input Type | AC |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Power (Watts) | 90 W |
| Size / Dimension [x] | 4.61 " |
| Size / Dimension [x] | 117.1 mm |
| Size / Dimension [y] | 50.8 mm |
| Size / Dimension [y] | 2 in |
| Size / Dimension [z] | 3.1 in |
| Size / Dimension [z] | 78.7 mm |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 199.00 | |
Description
General part information
SP-90W
AC/DC DIN RAIL SUPPLY 24V 90W
