Technical Specifications
Parameters and characteristics for this part
| Specification | MEOB-627PN-02-583 |
|---|---|
| Current - Supply | 500 µA |
| Direction | Omnidirectional |
| Frequency Range [Max] | 16 kHz |
| Frequency Range [Min] | 50 Hz |
| Height (Max) [Max] | 0.106 in |
| Height (Max) [Max] | 2.7 mm |
| Impedance | 2.2 kOhms |
| Output Type | Analog |
| Port Location | Top |
| Sensitivity | -58 dB |
| Shape | Circular |
| Size / Dimension [diameter] | 6 mm |
| Size / Dimension [diameter] | 0.236 in |
| Termination | PC Pins |
| Type | Electret Condenser |
| Voltage - Rated | 2 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
MEOB-627PN-02-583
50 Hz ~ 16 kHz Analog Microphone Electret Condenser Omnidirectional (-58dB ±3dB) PC Pins
