MSS1260H-104KED
ActiveCoilcraft
FIXED INDUCTOR 100UH SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MSS1260H-104KED
ActiveCoilcraft
FIXED INDUCTOR 100UH SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MSS1260H-104KED |
|---|---|
| Current - Saturation (Isat) | 2.2 A |
| Current Rating (Amps) | 1.3 A |
| DC Resistance (DCR) [Max] | 150 mOhm |
| Frequency - Self Resonant | 6.6 MHz |
| Height - Seated (Max) [Max] | 6.25 mm |
| Height - Seated (Max) [Max] | 0.246 " |
| Inductance | 100 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Size / Dimension [x] | 0.472 in |
| Size / Dimension [x] | 12 mm |
| Size / Dimension [y] | 0.472 " |
| Size / Dimension [y] | 12 mm |
| Tolerance | 10 % |
| Type | Drum Core |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
MSS1260H-104KED
100 µH Shielded Drum Core Inductor 1.3 A 150mOhm Max Nonstandard
