PSN30-15AC
ActiveAUTONICS
SENSOR PROX INDUCTIVE 15MM MOD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PSN30-15AC
ActiveAUTONICS
SENSOR PROX INDUCTIVE 15MM MOD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PSN30-15AC |
|---|---|
| Indicator [custom] | LED |
| Ingress Protection | IP67 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Output Type | NC, 2-Wire |
| Package / Case | Module |
| Response Frequency | 20 Hz |
| Sensing Distance | 15 mm |
| Sensing Distance | 0.591 " |
| Sensor Type | Inductive |
| Termination Style | Cable Leads |
| Voltage - Supply [Max] | 264 VAC |
| Voltage - Supply [Min] | 85 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 46.00 | |
Description
General part information
PSN30-15AC
SENSOR PROX INDUCTIVE 15MM MOD
Documents
Technical documentation and resources
