TX0444A
ActiveTST
122.88/50/7.0X5.0
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TX0444A
ActiveTST
122.88/50/7.0X5.0
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TX0444A |
|---|---|
| Absolute Pull Range (APR) | 50 ppm |
| Base Resonator | Crystal |
| Current - Supply (Max) [Max] | 80 mA |
| Frequency | 122.88 MHz |
| Function | Enable/Disable |
| Height - Seated (Max) [Max] | 0.071 " |
| Height - Seated (Max) [Max] | 1.8 mm |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output | PECL |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension [x] | 0.283 in |
| Size / Dimension [x] | 7.2 mm |
| Size / Dimension [y] | 5.2 mm |
| Size / Dimension [y] | 0.205 " |
| Type | VCXO |
| Voltage - Supply | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 6.87 | |
| 10 | $ 6.46 | |||
| 50 | $ 6.26 | |||
| 100 | $ 6.06 | |||
| 500 | $ 5.66 | |||
| 1000 | $ 5.05 | |||
| Digi-Reel® | 1 | $ 6.87 | ||
| 10 | $ 6.46 | |||
| 50 | $ 6.26 | |||
| 100 | $ 6.06 | |||
| 500 | $ 5.66 | |||
| 1000 | $ 5.05 | |||
| Tape & Reel (TR) | 3000 | $ 5.05 | ||
Description
General part information
TX0444A
122.88 MHz VCXO PECL Oscillator 3.3V Enable/Disable 6-SMD, No Lead
Documents
Technical documentation and resources
