0ACH-9600-TE
ActiveBEL MAGNETIC SOLUTIONS
FUSE BRD MT 60A 125VAC 72VDC SMD
Deep-Dive with AI
Search across all available documentation for this part.
0ACH-9600-TE
ActiveBEL MAGNETIC SOLUTIONS
FUSE BRD MT 60A 125VAC 72VDC SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 0ACH-9600-TE |
|---|---|
| Approval Agency | cURus, AEC-Q200 |
| Breaking Capacity @ Rated Voltage | 500 A, 1000 kA |
| Current Rating (Amps) | 60 A |
| DC Cold Resistance | 0.0006 Ohms |
| Fuse Type | Board Mount |
| Melting I²t | 900 |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 2-SMD, Square End Block |
| Response Time | Fast Blow |
| Size / Dimension [x] | 0.484 in |
| Size / Dimension [x] | 12.3 mm |
| Size / Dimension [y] | 4.5 mm |
| Size / Dimension [y] | 0.177 " |
| Size / Dimension [z] | 4.5 mm |
| Size / Dimension [z] | 0.177 in |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 72 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 6.42 | |
| 5 | $ 5.35 | |||
| 10 | $ 4.94 | |||
| 50 | $ 4.12 | |||
| 100 | $ 3.80 | |||
| 250 | $ 3.42 | |||
| 500 | $ 3.16 | |||
| Digi-Reel® | 1 | $ 6.42 | ||
| 5 | $ 5.35 | |||
| 10 | $ 4.94 | |||
| 50 | $ 4.12 | |||
| 100 | $ 3.80 | |||
| 250 | $ 3.42 | |||
| 500 | $ 3.16 | |||
| Tape & Reel (TR) | 1000 | $ 2.91 | ||
| 2000 | $ 2.69 | |||
Description
General part information
0ACH-9600-TE
60 A 125 V AC 72 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, Square End Block
Documents
Technical documentation and resources
No documents available
