CPC-500-27-BP2
ActiveGMW Associates
DC-AC CURRENT PROBE, CLIP-ON, 50
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CPC-500-27-BP2
ActiveGMW Associates
DC-AC CURRENT PROBE, CLIP-ON, 50
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CPC-500-27-BP2 |
|---|---|
| Accuracy | 1 % |
| Current - Sensing | 500 A |
| Current - Supply (Max) [Max] | 85 mA |
| For Measuring | AC/DC |
| Frequency [Max] | 75 kHz |
| Frequency [Min] | DC |
| Linearity | 0.2 % |
| Mounting Type | Free Hanging |
| Number of Channels | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Output | 2 V |
| Output | Ratiometric |
| Polarization | Bidirectional |
| Response Time | 10 µs |
| Sensor Type | Open Loop |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 3.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 440.00 | |
| 10 | $ 418.00 | |||
| 24 | $ 404.80 | |||
| 50 | $ 387.20 | |||
Description
General part information
CPC-500-27-BP2
Current Sensor 500A 1 Channel Open Loop Bidirectional Box
Documents
Technical documentation and resources
