MHW1306SG1R0M
ActiveMentech Technology USA Inc.
FIXED IND 1UH 20A 1.18 MOHM SMD
Deep-Dive with AI
Search across all available documentation for this part.
MHW1306SG1R0M
ActiveMentech Technology USA Inc.
FIXED IND 1UH 20A 1.18 MOHM SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MHW1306SG1R0M |
|---|---|
| Current - Saturation (Isat) | 30 A |
| Current Rating (Amps) | 20 A |
| DC Resistance (DCR) | 1.18 mOhm |
| Height - Seated (Max) [Max] [z] | 0.24 in |
| Height - Seated (Max) [Max] [z] | 6.1 mm |
| Inductance | 1 µH |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Size / Dimension [x] | 12.7 mm |
| Size / Dimension [y] | 0.492 ", 12.5 mm |
| Tolerance | 20 % |
| Type | Planar |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 450 | $ 1.28 | |
| 1800 | $ 1.22 | |||
| 3150 | $ 1.09 | |||
Description
General part information
MHW1306SG1R0M
1 µH Planar Inductor 20 A 1.18mOhm Max Nonstandard
Documents
Technical documentation and resources
No documents available
