D32D63CR03391JR/LS295
ActiveCalRamic Technologies LLC
3200V, CR03-N1500, 390PF, +/-5%,
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
D32D63CR03391JR/LS295
ActiveCalRamic Technologies LLC
3200V, CR03-N1500, 390PF, +/-5%,
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | D32D63CR03391JR/LS295 |
|---|---|
| Applications | General Purpose |
| Capacitance | 390 pF |
| Features | High Voltage |
| Height - Seated (Max) [Max] | 19.18 mm |
| Height - Seated (Max) [Max] | 0.755 " |
| Lead Spacing | 7.5 mm |
| Lead Spacing | 0.295 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Disc, Radial |
| Size / Dimension [diameter] | 0.63 in |
| Size / Dimension [diameter] | 16 mm |
| Temperature Coefficient | N1500 |
| Tolerance | 5 % |
| Voltage - Rated | 3150 V |
| Voltage - Rated | 3.15 kV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 14.46 | |
| 10 | $ 11.26 | |||
| 100 | $ 9.59 | |||
| 1000 | $ 8.71 | |||
Description
General part information
D32D63CR03391JR/LS295
390 pF ±5% 3150V (3.15kV) Ceramic Capacitor N1500 Radial, Disc
