TE0114A
ActiveTST
SAW DIPLEXER, SM5050-8PAD, 460.0
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TE0114A
ActiveTST
SAW DIPLEXER, SM5050-8PAD, 460.0
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TE0114A |
|---|---|
| Applications | General Purpose |
| Frequency - Center | 420 MHz, 460 MHz |
| Height (Max) [Max] | 0.067 " |
| Height (Max) [Max] | 1.7 mm |
| Insertion Loss | 2.1 dB |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, No Lead |
| Size / Dimension [x] | 0.197 in |
| Size / Dimension [x] | 5 mm |
| Size / Dimension [y] | 5 mm |
| Size / Dimension [y] | 0.197 " |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.12 | |
| 10 | $ 2.55 | |||
| 25 | $ 2.35 | |||
| 50 | $ 2.21 | |||
| 100 | $ 2.08 | |||
| 250 | $ 1.92 | |||
| 500 | $ 1.80 | |||
| Digi-Reel® | 1 | $ 3.12 | ||
| 10 | $ 2.55 | |||
| 25 | $ 2.35 | |||
| 50 | $ 2.21 | |||
| 100 | $ 2.08 | |||
| 250 | $ 1.92 | |||
| 500 | $ 1.80 | |||
| Tape & Reel (TR) | 1000 | $ 1.69 | ||
| 2000 | $ 1.59 | |||
| 3000 | $ 1.54 | |||
| 5000 | $ 1.50 | |||
Description
General part information
TE0114A
460MHz, 420MHz Frequency General Purpose RF SAW Filter (Surface Acoustic Wave) 2.1dB 20MHz Bandwidth 8-SMD, No Lead
