UTD2102CL+
ActiveUni-Trend Technology US Inc
DIGITAL OSCILLOSCOPES 100MHZ
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
UTD2102CL+
ActiveUni-Trend Technology US Inc
DIGITAL OSCILLOSCOPES 100MHZ
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | UTD2102CL+ |
|---|---|
| Bandwidth | 100 MHz |
| Channels | 2 Analog |
| Display Type | LCD |
| Function | Save, Playback, Record |
| Includes | Connector, Software |
| Input Impedance | 1 MΩ, 18 pF |
| Interface | USB |
| Memory Size | 64 kpts |
| Rise Time (Typ) | 3.5 ns |
| Sampling Rate (Per Second) | 500 M |
| Type | Bench, Digital |
| Voltage - Supply [Max] | 240 VAC |
| Voltage - Supply [Min] | 100 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Retail Package | 1 | $ 219.00 | |
Description
General part information
UTD2102CL+
100 MHz Bench, Digital Oscilloscopes USB Interface LCD Display 2 Analog Channel Record, Playback, Save
