IR-0422H
ActiveDIT
LINE FLTR 250VAC/VDC 4A PANEL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
IR-0422H
ActiveDIT
LINE FLTR 250VAC/VDC 4A PANEL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | IR-0422H |
|---|---|
| Applications | General Purpose |
| Approval Agency | UR, CSA, TUV |
| Configuration | Single Stage |
| Current | 4 A |
| Filter Type | Single Phase |
| Frequency - Operating [Max] | 60 Hz |
| Frequency - Operating [Min] | 50 Hz |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -25 °C |
| Termination Style | Quick Connect, IEC 320-C14 |
| Voltage - Rated AC | 250 V |
| Voltage - Rated DC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 10.81 | |
| 10 | $ 9.19 | |||
| 25 | $ 8.61 | |||
| 50 | $ 8.20 | |||
| 100 | $ 7.81 | |||
| 300 | $ 7.23 | |||
| 500 | $ 6.97 | |||
| 1000 | $ 6.64 | |||
Description
General part information
IR-0422H
Single Phase EMC/EMI Line Filter 4 A 250V 250V 50 ~ 60Hz Single Stage IEC 320-C14, Quick Connect
