37532
UnknownSchott Corporation
TRANSF QUAD T1/E1 1:1.36CT SMD
Deep-Dive with AI
Search across all available documentation for this part.
37532
UnknownSchott Corporation
TRANSF QUAD T1/E1 1:1.36CT SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 37532 |
|---|---|
| Height - Seated (Max) [Max] | 7.37 mm |
| Height - Seated (Max) [Max] [z] | 0.29 " |
| Inductance | 1.2 mH |
| Mounting Type | Surface Mount |
| Size / Dimension [x] | 1 in |
| Size / Dimension [x] | 25.4 mm |
| Size / Dimension [y] | 0.3 " |
| Size / Dimension [y] | 7.62 mm |
| Transformer Type | T1/E1 |
| Turns Ratio - Primary:Secondary | 1:1.36CT |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.73 | |
| 10 | $ 2.67 | |||
| 25 | $ 2.61 | |||
| 250 | $ 2.56 | |||
| Tape & Reel (TR) | 500 | $ 2.51 | ||
Description
General part information
37532
1.2mH T1/E1 (Quad) Pulse Transformer 1:1.36CT Surface Mount
Documents
Technical documentation and resources
No documents available
