LR20 F/BF5
ActiveFDK America, Inc., a member of Fujitsu Group
BATTERY PACK ALKALINE 7.5V D
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
LR20 F/BF5
ActiveFDK America, Inc., a member of Fujitsu Group
BATTERY PACK ALKALINE 7.5V D
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | LR20 F/BF5 |
|---|---|
| Battery Cell Size | D |
| Battery Chemistry | Alkaline Manganese Dioxide |
| Capacity | 15.25 Ah |
| Number of Cells | 5 |
| Rechargeability | False |
| Size / Dimension [x] | 171 mm |
| Size / Dimension [x] | 6.73 in |
| Size / Dimension [y] | 34.2 mm |
| Size / Dimension [y] | 1.35 in |
| Size / Dimension [z] | 61.5 mm |
| Size / Dimension [z] | 2.42 " |
| Structure | Side to Side |
| Structure [custom] | 5 Cells |
| Structure [custom] | 1 |
| Termination Style | Solder Tab |
| Voltage - Rated | 7.5 VDC |
| Weight | 655 g |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 23.76 | |
| 10 | $ 19.67 | |||
| 50 | $ 17.24 | |||
| 100 | $ 16.26 | |||
| 250 | $ 15.09 | |||
| 500 | $ 14.22 | |||
Description
General part information
LR20 F/BF5
D 7.5 V Alkaline Manganese Dioxide Battery Pack
