8009-03P-0121-05
ActiveE Connector Solutions
CONN D-SUB PLUG 9POS VERT SOLDER
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
8009-03P-0121-05
ActiveE Connector Solutions
CONN D-SUB PLUG 9POS VERT SOLDER
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 8009-03P-0121-05 |
|---|---|
| Color | White |
| Connector Style | D-Sub |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Contact Material | Phosphor Bronze |
| Contact Type | Signal |
| Current Rating (Amps) | 5 A |
| Dielectric Material | Glass Filled, Nylon 6T, Polyamide (PA6T) |
| Features | Grounding Indents |
| Flange Feature | Housing/Shell (Unthreaded) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Primary Material | Metal |
| Shell Size, Connector Layout [custom] | DE, E |
| Shell Size, Connector Layout [custom] | 1 |
| Termination | Solder |
| Voltage Rating | 250 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 100 | $ 1.98 | |
Description
General part information
8009-03P-0121-05
9 Position D-Sub Plug, Male Pins Connector
