VTX-146-100-215
ActiveVIGORTRONIX
100VA TOROIDAL TRANSFORMER 2X15V
Deep-Dive with AI
Search across all available documentation for this part.
VTX-146-100-215
ActiveVIGORTRONIX
100VA TOROIDAL TRANSFORMER 2X15V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | VTX-146-100-215 |
|---|---|
| Center Tap | False |
| Current - Output (Max) [Max] | 3.33 A |
| Height - Seated (Max) [Max] | 45 mm |
| Mounting Type | Chassis Mount |
| Power - Max [Max] | 100 VA |
| Primary Winding(s) | Dual |
| Secondary Winding(s) | Dual |
| Size / Dimension [diameter] | 91 mm |
| Termination Style | Wire Leads |
| Type | Toroidal |
| Voltage - Isolation | 4200 Vrms |
| Voltage - Primary | 115 V, 230 V |
| Voltage - Secondary (Full Load) | 30 V, 15 V |
| Weight | 2.4 lbs |
| Weight | 1.1 kg |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
VTX-146-100-215
100VA TOROIDAL TRANSFORMER 2X15V
Documents
Technical documentation and resources
