CMD-120-ASE-5
ActiveATC-Diversified Electronics
UNIVERSAL AC CURRENT MONITOR
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CMD-120-ASE-5
ActiveATC-Diversified Electronics
UNIVERSAL AC CURRENT MONITOR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CMD-120-ASE-5 |
|---|---|
| Circuit | DPDT (2 Form C) |
| Contact Rating @ Voltage [x] | 10 A, 120 VAC |
| Delay Time [Max] | 30 Sec |
| Delay Time [Min] | 0.1 Sec |
| Mounting Type | Chassis Mount |
| Trip Range [Max] | 5 A AC |
| Trip Range [Min] | 1 A AC |
| Trip Status | Energized High/Low |
| Type | Current Sensing AC |
| Voltage - Supply | 120 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 416.61 | |
Description
General part information
CMD-120-ASE-5
Current Sensing AC 120VAC
Documents
Technical documentation and resources
