SFV25D511K
ActiveSETsafe | SETfuse
METAL OXIDE VARISTOR
Deep-Dive with AI
Search across all available documentation for this part.
SFV25D511K
ActiveSETsafe | SETfuse
METAL OXIDE VARISTOR
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SFV25D511K |
|---|---|
| Capacitance @ Frequency | 1250 pF |
| Current - Surge | 20 kA |
| Energy | 420 J |
| Maximum AC Volts [Max] | 320 V |
| Maximum DC Volts [Max] | 415 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 105 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Disc |
| Package / Case [diameter] | 25 mm |
| Varistor Voltage (Max) [Max] | 561 V |
| Varistor Voltage (Min) [Min] | 459 V |
| Varistor Voltage (Typ) | 510 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 2.45 | |
| 100 | $ 1.47 | |||
| 400 | $ 1.20 | |||
Description
General part information
SFV25D511K
510 V 20 kA Varistor 1 Circuit Through Hole Disc 25mm
Documents
Technical documentation and resources
No documents available
