SVG063M101GCBPE50V00A
ActiveSuscon
CAP ALUM 100UF 20% 63V SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SVG063M101GCBPE50V00A
ActiveSuscon
CAP ALUM 100UF 20% 63V SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SVG063M101GCBPE50V00A |
|---|---|
| Applications | Automotive |
| Capacitance | 100 µF |
| Height - Seated (Max) [Max] | 0.492 in |
| Height - Seated (Max) [Max] | 12.5 mm |
| Lifetime @ Temp. | 4000 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Radial, Can - SMD |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current @ High Frequency | 2 A |
| Ripple Current @ Low Frequency | 200 mA |
| Size / Dimension [diameter] | 10 mm |
| Size / Dimension [diameter] | 0.394 in |
| Surface Mount Land Size [x] | 0.406 in |
| Surface Mount Land Size [x] | 10.3 mm |
| Surface Mount Land Size [y] | 10.3 mm |
| Surface Mount Land Size [y] | 0.406 " |
| Tolerance | 20 % |
| Voltage - Rated | 63 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 5 | $ 1.22 | |
| 50 | $ 1.13 | |||
| 100 | $ 0.98 | |||
| 400 | $ 0.89 | |||
| 800 | $ 0.88 | |||
Description
General part information
SVG063M101GCBPE50V00A
100 µF 63 V Aluminum Electrolytic Capacitors Radial, Can - SMD 4000 Hrs @ 125°C
