UPO1104
ActiveUni-Trend Technology US Inc
100MHZ 4CH ULTRA PHOSPHOR DIGITA
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
UPO1104
ActiveUni-Trend Technology US Inc
100MHZ 4CH ULTRA PHOSPHOR DIGITA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | UPO1104 |
|---|---|
| Bandwidth | 200 MHz |
| Channels | 4 |
| Display Type | LCD - Color |
| Function | Save, Playback, Record |
| Includes | Software |
| Input Impedance | 16 pF, 1 MΩ |
| Interface | USB |
| Memory Size | 56 Mpts |
| Probe Type | Passive 10:1 (1) |
| Rise Time (Typ) | 3.5 ns |
| Sampling Rate (Per Second) | 2 G |
| Type | Bench |
| Voltage - Input (Max) [Max] | 400 V |
| Voltage - Supply [Max] | 240 VAC |
| Voltage - Supply [Min] | 100 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Retail Package | 1 | $ 391.20 | |
Description
General part information
UPO1104
200 MHz Bench Oscilloscopes USB Interface LCD - Color Display 4 Channel 400V Record, Playback, Save
