CFM-4015B-175-287-20
ActiveCUI Devices
DC AXIAL FAN, 40 MM SQUARE, 15 M
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-4015B-175-287-20 |
|---|---|
| Air Flow | 0.235 mł/min |
| Air Flow | 8.4 CFM |
| Approval Agency | cURus, CE, TUV |
| Bearing Type | Ball |
| Current Rating (Amps) | 100 mA |
| Fan Type | Tubeaxial |
| Features | Auto Restart, Speed Sensor (Tach) |
| Lifetime @ Temp. | 70000 Hrs |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Noise | 28.7 dB(A) |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -10 °C |
| Operating Temperature [Min] | -10 °C |
| Power (Watts) | 1.2 W |
| RPM | 7500 RPM |
| Size / Dimension | Square |
| Size / Dimension [x] | 40 mm |
| Size / Dimension [z] | 40 mm |
| Static Pressure | 72.2 Pa |
| Static Pressure | 0.29 in H2O |
| Termination | 3 Wire Leads |
| Voltage - Rated | 12 VDC |
| Voltage Range [Max] | 13.2 VDC |
| Voltage Range [Min] | 10.8 VDC |
| Width [y] | 15.1 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 960 | $ 7.93 | |
Description
General part information
CFM-4015B-175-287-20
Fan Tubeaxial 12VDC Square - 40mm L x 40mm H Ball 8.4 CFM (0.235m³/min) 3 Wire Leads
