CPT6030-ACPG000000-000500JS-1KZ-ZZ
ActiveMensor
SENSOR 5PSIG 1/4"NPT .02A
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CPT6030-ACPG000000-000500JS-1KZ-ZZ
ActiveMensor
SENSOR 5PSIG 1/4"NPT .02A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CPT6030-ACPG000000-000500JS-1KZ-ZZ |
|---|---|
| Accuracy | 0.025 % FS |
| Operating Pressure | 34.47 kPa |
| Operating Pressure | 5 PSI |
| Output [Max] | 20 mA |
| Output [Min] | 4 mA |
| Output Type | Analog Current |
| Port Size [custom] | NPT |
| Port Size [custom] | Male |
| Port Size [x] | 0.25 " |
| Port Size [x] | 6.35 mm |
| Pressure Type | Gauge |
| Termination Style | Wire Leads |
| Voltage - Supply | 24 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 1453.40 | |
Description
General part information
CPT6030-ACPG000000-000500JS-1KZ-ZZ
Pressure Sensor 5PSI (34.47kPa) Gauge Male - 1/4" (6.35mm) NPT 4 ~ 20mA
