110-A-111/03
ActiveWECO Electrical Connectors Inc.
PLUG PLUG-IN SCREW 3POS 3.5MM PI
Deep-Dive with AI
Search across all available documentation for this part.
110-A-111/03
ActiveWECO Electrical Connectors Inc.
PLUG PLUG-IN SCREW 3POS 3.5MM PI
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 110-A-111/03 |
|---|---|
| Color | Gray |
| Contact Material | Copper Alloy |
| Contact Mating Finish | Tin |
| Current - UL | 8 A |
| Housing Material | Polyamide (PA), Nylon |
| Insulation Height | 0.43 in |
| Insulation Height | 10.92 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 3.5 mm |
| Pitch [x] | 0.138 in |
| Positions Per Level | 3 |
| Screw Size | M2 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw | 0.2 Nm |
| Torque - Screw | 1.7 Lb-In |
| Type | Plug, Female Sockets |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG [Max] | 30 AWG |
| Wire Gauge or Range - AWG [Min] | 16 AWG |
| Wire Gauge or Range - mm² | 1.5 mm² |
| Wire Strip Length | 6 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 2.71 | |
| 10 | $ 1.69 | |||
| 25 | $ 1.49 | |||
| 50 | $ 1.38 | |||
| 100 | $ 1.30 | |||
| 250 | $ 1.22 | |||
| 500 | $ 1.18 | |||
| 1000 | $ 1.15 | |||
| 5000 | $ 1.10 | |||
Description
General part information
110-A-111/03
3 Position Terminal Block Plug, Female Sockets 0.138" (3.50mm) 180° Free Hanging (In-Line)
