D1MPAC2512QR033FA-T4
ActiveThin Film Technology Corp.
RES 0.033 OHM 1% 3W 2512
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
D1MPAC2512QR033FA-T4
ActiveThin Film Technology Corp.
RES 0.033 OHM 1% 3W 2512
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | D1MPAC2512QR033FA-T4 |
|---|---|
| Composition | Metal Element |
| Features | Flame Retardant Coating, Moisture Resistant, Current Sense, Anti-Sulfur, Safety |
| Height - Seated (Max) [Max] [z] | 0.043 in |
| Height - Seated (Max) [Max] [z] | 1.1 mm |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 170 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 6432 Metric |
| Package / Case | 2512 |
| Power (Watts) | 3 W |
| Resistance | 33 mOhms |
| Supplier Device Package | 2512 |
| Temperature Coefficient | 50 ppm/°C |
| Tolerance | 1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.77 | |
| 10 | $ 0.44 | |||
| 25 | $ 0.36 | |||
| 50 | $ 0.30 | |||
| 100 | $ 0.26 | |||
| 250 | $ 0.22 | |||
| 500 | $ 0.19 | |||
| 1000 | $ 0.17 | |||
| Tape & Reel (TR) | 4000 | $ 0.13 | ||
| 8000 | $ 0.13 | |||
Description
General part information
D1MPAC2512QR033FA-T4
33 mOhms ±1% 3W Chip Resistor 2512 (6432 Metric) Anti-Sulfur, Current Sense, Flame Retardant Coating, Moisture Resistant, Safety Metal Element
