ITX-P-C444D-2-16
ActiveWINSYSTEMS, INC
SBC 1.3GHZ 2 CORE 2GB/0GB RAM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ITX-P-C444D-2-16
ActiveWINSYSTEMS, INC
SBC 1.3GHZ 2 CORE 2GB/0GB RAM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ITX-P-C444D-2-16 |
|---|---|
| Contents | SD Card |
| Core Processor | ARM® Cortex®-M4, ARM® Cortex®-A53, i.MX8M Dual |
| Ethernet | GbE (2) |
| Expansion Site/Bus | mPCIe |
| Form Factor | Pico-ITX |
| Number of Cores | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| RAM Capacity/Installed | 0 GB, 2 GB |
| RS-232 (422, 485) | 2 |
| Size / Dimension [x] | 3.93 in |
| Size / Dimension [x] | 99.82 mm |
| Size / Dimension [y] | 2.83 in |
| Size / Dimension [y] | 71.88 mm |
| Speed | 1.3 GHz |
| Storage Interface | eMMC, microSD |
| USB | USB 3.1 (1), USB 2.0 (3) |
| Video Outputs | HDMI, LVDS |
| Watchdog Timer | False |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 636.00 | |
Description
General part information
ITX-P-C444D-2-16
Single Board Computer 1.3GHz 2 Core 2GB/0GB RAM ARM® Cortex®-A53, ARM® Cortex®-M4, i.MX8M Dual
