099170
ActiveDVTEST
DBDIRECT QRBH ANTENNA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 099170 |
|---|---|
| Antenna Type | Module |
| Applications | 3G, Bluetooth, 5G, 4G, GSM, LTE, WiMax, GPS, Wi-Fi, LoRa |
| Frequency (Center/Band) | 3.15 GHz |
| Frequency Group | Wide Band |
| Frequency Range [Max] | 6 GHz |
| Frequency Range [Min] | 300 MHz |
| Gain | 14 dBi |
| Height (Max) [Max] | 19.96 in |
| Height (Max) [Max] | 506.98 mm |
| Mounting Type | Base Mount |
| Number of Bands | 1 |
| Power - Max [Max] | 500 W |
| RF Family/Standard | Cellular, WiFi |
| Termination | N Type Female |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
099170
3.15GHz 3G, 4G, 5G, Bluetooth, GPS, GSM, LoRa, LTE, Wi-Fi, WiMax Module RF Antenna 300MHz ~ 6GHz 14dBi N Type Female Base Mount
