MVH4002D
ActiveMEMS Vision
DIGITAL RH&T SENSOR
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MVH4002D
ActiveMEMS Vision
DIGITAL RH&T SENSOR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MVH4002D |
|---|---|
| Accuracy | 2 % |
| Humidity Range [Max] | 100 % RH |
| Humidity Range [Min] | 0 % RH |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Output | 14 b |
| Output Type | I2C |
| Package / Case | 8-VFDFN Exposed Pad |
| Response Time | 4 s |
| Sensor Type | Temperature, Humidity |
| Supplier Device Package | 8-LGA (2.5x2.5) |
| Voltage - Supply [Max] | 3.6 V |
| Voltage - Supply [Min] | 1.71 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1 | $ 2.50 | |
| 5 | $ 2.20 | |||
| 10 | $ 1.95 | |||
| 25 | $ 1.58 | |||
| 50 | $ 1.40 | |||
| 100 | $ 1.36 | |||
| 500 | $ 1.14 | |||
| 1000 | $ 1.07 | |||
| 2500 | $ 1.03 | |||
Description
General part information
MVH4002D
Humidity, Temperature 0 ~ 100% RH I2C ±2% RH 4 s Surface Mount
