AM-1111
ActiveAtlanta Micro Inc.
2.0 GHZ TO 18.0 GHZ DRIVER AMPLI
Deep-Dive with AI
Search across all available documentation for this part.
AM-1111
ActiveAtlanta Micro Inc.
2.0 GHZ TO 18.0 GHZ DRIVER AMPLI
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AM-1111 |
|---|---|
| Current - Supply | 100 mA |
| Frequency | 18 GHz |
| Gain | 16 dB |
| Mounting Type | Surface Mount |
| Noise Figure | 2 dB |
| P1dB | 21 dBm |
| Package / Case | 12-LFQFN Exposed Pad |
| RF Type | General Purpose |
| Supplier Device Package | 12-QFN (3x3) |
| Test Frequency | 10 GHz |
| Voltage - Supply | 5.2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Strip | 10 | $ 110.00 | |
Description
General part information
AM-1111
RF Amplifier IC General Purpose 18GHz 12-QFN (3x3)
Documents
Technical documentation and resources
No documents available
