049ST2-7.680F16DTLJK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
49S DIP 2PIN 7.68MHZ,16PF,+/-20
Deep-Dive with AI
Search across all available documentation for this part.
049ST2-7.680F16DTLJK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
49S DIP 2PIN 7.68MHZ,16PF,+/-20
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 049ST2-7.680F16DTLJK |
|---|---|
| ESR (Equivalent Series Resistance) | 65 Ohms |
| Frequency Stability | 30 ppm |
| Frequency Tolerance | 20 ppm |
| Height - Seated (Max) [Max] [z] | 3.5 mm |
| Height - Seated (Max) [Max] [z] | 0.138 in |
| Load Capacitance | 16 pF |
| Mounting Type | Through Hole |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Radial, Can - SMD |
| Size / Dimension [x] | 11.4 mm |
| Size / Dimension [x] | 0.449 " |
| Size / Dimension [y] | 0.181 in |
| Size / Dimension [y] | 4.6 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Strip | 10 | $ 0.34 | |
| 100 | $ 0.32 | |||
| 500 | $ 0.29 | |||
| 1000 | $ 0.28 | |||
| 3000 | $ 0.09 | |||
| Tape & Reel (TR) | 1000 | $ 0.28 | ||
| 3000 | $ 0.26 | |||
| 6000 | $ 0.25 | |||
| 9000 | $ 0.24 | |||
Description
General part information
049ST2-7.680F16DTLJK
±20ppm Crystal 16pF 65 Ohms Radial, Can - SMD
Documents
Technical documentation and resources
No documents available
