300056
ActiveAmphenol Alden Products Company
CONN PLUG MALE 7P GOLD SLDR CUP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
300056
ActiveAmphenol Alden Products Company
CONN PLUG MALE 7P GOLD SLDR CUP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 300056 |
|---|---|
| Applications | Medical |
| Color | Black |
| Connector Type | Plug, Male Pins |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 10 çin |
| Contact Finish Thickness - Mating | 0.25 çm |
| Contact Material | Brass |
| Current Rating (Amps) | 2.1 A |
| Fastening Type | Latch Lock |
| Features | Strain Relief |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 7 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -20 C |
| Orientation | 1 |
| Primary Material | Plastic |
| Shielding | Unshielded |
| Voltage Rating | 300 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 21.53 | |
| 5 | $ 42.02 | |||
| 10 | $ 20.49 | |||
Description
General part information
300056
7 Position Circular Connector Plug, Male Pins Solder Cup
