CM4024M00009T1521007
ActiveHefei Jingweite Electronics Co., Ltd.
2520 XTAL 24M 8PF 10 20 -40/85 4
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CM4024M00009T1521007 |
|---|---|
| ESR (Equivalent Series Resistance) | 60 Ohms |
| Frequency | 24 MHz |
| Frequency Stability | 20 ppm |
| Frequency Tolerance | 10 ppm |
| Height - Seated (Max) [Max] [z] | 0.6 mm |
| Height - Seated (Max) [Max] [z] | 0.024 in |
| Load Capacitance | 8 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 2.55 mm |
| Size / Dimension [x] | 0.1 in |
| Size / Dimension [y] | 0.081 " |
| Size / Dimension [y] | 2.05 mm |
| Type | MHz Crystal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 3000 | $ 0.12 | |
| 6000 | $ 0.11 | |||
| 9000 | $ 0.11 | |||
| 15000 | $ 0.10 | |||
| 21000 | $ 0.10 | |||
| 30000 | $ 0.10 | |||
| 75000 | $ 0.09 | |||
Description
General part information
CM4024M00009T1521007
24 MHz ±10ppm Crystal 8pF 60 Ohms 4-SMD, No Lead
