HNA800480T030-ZHC
ActivePowertip Technology Inc.
5" TFT LCD DISPLAY, 800X480 DOTS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
HNA800480T030-ZHC
ActivePowertip Technology Inc.
5" TFT LCD DISPLAY, 800X480 DOTS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | HNA800480T030-ZHC |
|---|---|
| Background Color | Black |
| Backlight | Without Backlight |
| Controller Type | N32926 |
| Diagonal Screen Size [custom] | 127 mm |
| Diagonal Screen Size [custom] | 5 in |
| Display Mode | Transmissive |
| Display Type | TFT - Color |
| Dot Pixels | WVGA |
| Dot Pixels [x] | 800 |
| Dot Pixels [y] | 480 |
| Dot Size [x] | 0.14 mm |
| Dot Size [y] | 0.14 mm |
| Graphics Color | Green, Red, Blue |
| Interface | Parallel, USB, UART, 16-Bit (RGB) |
| Touchscreen | Capacitive |
| Viewing Area [x] | 109 mm |
| Viewing Area [y] | 65.8 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Box (TB) | 1 | $ 88.85 | |
Description
General part information
HNA800480T030-ZHC
Capacitive Graphic LCD Display Module Transmissive Red, Green, Blue (RGB) TFT - Color Parallel, 16-Bit (RGB), UART, USB 5" (127.00mm) 800 x 480 (WVGA)
